Western blot (WB): | 1:500-2000 |
Immunocytochemistry/Immunofluorescence (ICC/IF): | 1:50-200 |
Figure 1. Western blot analysis of anti-PGC1 Alpha/PPARGC1A antibody (BM4898). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: rat heart tissue lysates,
Lane 2: rat liver tissue lysates,
Lane 3: mouse heart tissue lysates,
Lane 4: mouse liver tissue lysates.
After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-PGC1 Alpha/PPARGC1A antigen affinity purified monoclonal antibody (BM4898) at a dilution of 1:1000 and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for PGC1 Alpha/PPARGC1A at approximately 113 kDa. The expected band size for PGC1 Alpha/PPARGC1A is at 91 kDa.
Figure 2. Western blot analysis of anti-PGC1 Alpha/PPARGC1A antibody (BM4898). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: rat liver tissue lysates,
Lane 2: rat C6 whole cell lysates,
Lane 3: mouse liver tissue lysates,
Lane 4: mouse NIH/3T3 whole cell lysates.
After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-PGC1 Alpha/PPARGC1A antigen affinity purified monoclonal antibody (BM4898) at a dilution of 1:1000 and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for PGC1 Alpha/PPARGC1A at approximately 113 kDa. The expected band size for PGC1 Alpha/PPARGC1A is at 91 kDa.
Immunofluorescent analysis using the Antibody.
Figure 1. Western blot analysis of anti-PGC1 Alpha/PPARGC1A antibody (BM4898). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: rat heart tissue lysates,
Lane 2: rat liver tissue lysates,
Lane 3: mouse heart tissue lysates,
Lane 4: mouse liver tissue lysates.
After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-PGC1 Alpha/PPARGC1A antigen affinity purified monoclonal antibody (BM4898) at a dilution of 1:1000 and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for PGC1 Alpha/PPARGC1A at approximately 113 kDa. The expected band size for PGC1 Alpha/PPARGC1A is at 91 kDa.
Figure 2. Western blot analysis of anti-PGC1 Alpha/PPARGC1A antibody (BM4898). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: rat liver tissue lysates,
Lane 2: rat C6 whole cell lysates,
Lane 3: mouse liver tissue lysates,
Lane 4: mouse NIH/3T3 whole cell lysates.
After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-PGC1 Alpha/PPARGC1A antigen affinity purified monoclonal antibody (BM4898) at a dilution of 1:1000 and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for PGC1 Alpha/PPARGC1A at approximately 113 kDa. The expected band size for PGC1 Alpha/PPARGC1A is at 91 kDa.
Immunofluorescent analysis using the Antibody.
