Figure 1. Western blot analysis of anti-NRF2/NFE2L2 antibody (A00078-1). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: human HepG2 whole cell lysates,
Lane 2: human SW620 whole cell lysates.
After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-NRF2/NFE2L2 antigen affinity purified polyclonal antibody (A00078-1) and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for NRF2/NFE2L2 at approximately 100 kDa. The expected band size for NRF2/NFE2L2 is at 100 kDa.
Figure 2. IHC analysis of NRF2/NFE2L2 using anti-NRF2/NFE2L2 antibody (A00078-1).
NRF2/NFE2L2 was detected in a paraffin-embedded section of human mammary cancer tissue. The tissue section was developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.
Figure 3. IF analysis of NRF2/NFE2L2 using anti-NRF2/NFE2L2 antibody (A00078-1).
NRF2/NFE2L2 was detected in an immunocytochemical section of U2OS cells. DyLight®488 Conjugated Goat Anti-Rabbit IgG (Green) (Catalog # BA1127) was used as secondary antibody. The section was counterstained with DAPI (Catalog # AR1176) (Blue).
Figure 4. Flow Cytometry analysis of 293T cells using anti-NRF2/NFE2L2 antibody (A00078-1).
Overlay histogram showing 293T cells stained with A00078-1 (Blue line). To facilitate intracellular staining, cells were fixed with 4% paraformaldehyde and permeabilized with permeabilization buffer. The cells were blocked with 10% normal goat serum. And then incubated with rabbit anti-NRF2/NFE2L2 Antibody (A00078-1) at 1:100 dilution for 30 min at 20°C. DyLight®488 conjugated goat anti-rabbit IgG (BA1127) was used as secondary antibody at 1:100 dilution for 30 minutes at 20°C. Isotype control antibody (Green line) was rabbit IgG at 1:100 dilution used under the same conditions. Unlabelled sample without incubation with primary antibody and secondary antibody (Red line) was used as a blank control.
| Western blot (WB): | 1:500-2000 |
| Immunohistochemistry (IHC): | 1:50-400 |
| Immunocytochemistry/Immunofluorescence (ICC/IF): | 1:50-400 |
| Flow Cytometry (Fixed): | 1:50-200 |
| Enzyme linked immunosorbent assay (ELISA): | 1:100-1000 |
| (Boiling the paraffin sections in 10mM citrate buffer,pH6.0,or PH8.0 EDTA repair liquid for 20 mins is required for the staining of formalin/paraffin sections.) Optimal working dilutions must be determined by end user. | |
Figure 1. Western blot analysis of anti-NRF2/NFE2L2 antibody (A00078-1). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: human HepG2 whole cell lysates,
Lane 2: human SW620 whole cell lysates.
After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-NRF2/NFE2L2 antigen affinity purified polyclonal antibody (A00078-1) and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for NRF2/NFE2L2 at approximately 100 kDa. The expected band size for NRF2/NFE2L2 is at 100 kDa.
Figure 2. IHC analysis of NRF2/NFE2L2 using anti-NRF2/NFE2L2 antibody (A00078-1).
NRF2/NFE2L2 was detected in a paraffin-embedded section of human mammary cancer tissue. The tissue section was developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.
Figure 3. IF analysis of NRF2/NFE2L2 using anti-NRF2/NFE2L2 antibody (A00078-1).
NRF2/NFE2L2 was detected in an immunocytochemical section of U2OS cells. DyLight®488 Conjugated Goat Anti-Rabbit IgG (Green) (Catalog # BA1127) was used as secondary antibody. The section was counterstained with DAPI (Catalog # AR1176) (Blue).
Figure 4. Flow Cytometry analysis of 293T cells using anti-NRF2/NFE2L2 antibody (A00078-1).
Overlay histogram showing 293T cells stained with A00078-1 (Blue line). To facilitate intracellular staining, cells were fixed with 4% paraformaldehyde and permeabilized with permeabilization buffer. The cells were blocked with 10% normal goat serum. And then incubated with rabbit anti-NRF2/NFE2L2 Antibody (A00078-1) at 1:100 dilution for 30 min at 20°C. DyLight®488 conjugated goat anti-rabbit IgG (BA1127) was used as secondary antibody at 1:100 dilution for 30 minutes at 20°C. Isotype control antibody (Green line) was rabbit IgG at 1:100 dilution used under the same conditions. Unlabelled sample without incubation with primary antibody and secondary antibody (Red line) was used as a blank control.
Figure 1. Western blot analysis of anti-NRF2/NFE2L2 antibody (A00078-1). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: human HepG2 whole cell lysates,
Lane 2: human SW620 whole cell lysates.
After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-NRF2/NFE2L2 antigen affinity purified polyclonal antibody (A00078-1) and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for NRF2/NFE2L2 at approximately 100 kDa. The expected band size for NRF2/NFE2L2 is at 100 kDa.
Figure 2. IHC analysis of NRF2/NFE2L2 using anti-NRF2/NFE2L2 antibody (A00078-1).
NRF2/NFE2L2 was detected in a paraffin-embedded section of human mammary cancer tissue. The tissue section was developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.
Figure 3. IF analysis of NRF2/NFE2L2 using anti-NRF2/NFE2L2 antibody (A00078-1).
NRF2/NFE2L2 was detected in an immunocytochemical section of U2OS cells. DyLight®488 Conjugated Goat Anti-Rabbit IgG (Green) (Catalog # BA1127) was used as secondary antibody. The section was counterstained with DAPI (Catalog # AR1176) (Blue).
Figure 4. Flow Cytometry analysis of 293T cells using anti-NRF2/NFE2L2 antibody (A00078-1).
Overlay histogram showing 293T cells stained with A00078-1 (Blue line). To facilitate intracellular staining, cells were fixed with 4% paraformaldehyde and permeabilized with permeabilization buffer. The cells were blocked with 10% normal goat serum. And then incubated with rabbit anti-NRF2/NFE2L2 Antibody (A00078-1) at 1:100 dilution for 30 min at 20°C. DyLight®488 conjugated goat anti-rabbit IgG (BA1127) was used as secondary antibody at 1:100 dilution for 30 minutes at 20°C. Isotype control antibody (Green line) was rabbit IgG at 1:100 dilution used under the same conditions. Unlabelled sample without incubation with primary antibody and secondary antibody (Red line) was used as a blank control.
