Anti-HSP60/HSPD1 Antibody

筛选器： All WB IHC ICC/IF

•

  Figure 1. Western blot analysis of HSP60/HSPD1 using anti-HSP60/HSPD1 antibody (PB9337). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
  Lane 1: human Hela whole cell lysates,
  Lane 2: human A549 whole cell lysates,
  Lane 3: human PANC-1 whole cell lysates,
  Lane 4: human MCF-7 whole cell lysates,
  Lane 5: rat liver tissue lysates,
  Lane 6: mouse liver tissue lysates,
  Lane 7: mouse thymus tissue lysates.
  After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-HSP60/HSPD1 antigen affinity purified polyclonal antibody (PB9337) at a dilution of 1:1000 and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for HSP60/HSPD1 at approximately 61 kDa. The expected band size for HSP60/HSPD1 is at 61 kDa.

•

  Figure 2. IHC analysis of Hsp60 using anti-Hsp60 antibody (PB9337).Hsp60 was detected in paraffin-embedded section of Mouse Intestine Tissue. Heat mediated antigen retrieval was performed in citrate buffer (pH6, epitope retrieval solution) for 20 mins. The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 1μg/ml rabbit anti-Hsp60 Antibody (PB9337) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC)(Catalog # SA1022) with DAB as the chromogen.

•

  Figure 3. IHC analysis of Hsp60 using anti-Hsp60 antibody (PB9337).Hsp60 was detected in paraffin-embedded section of Rat Intestine Tissue. Heat mediated antigen retrieval was performed in citrate buffer (pH6, epitope retrieval solution) for 20 mins. The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 1μg/ml rabbit anti-Hsp60 Antibody (PB9337) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC)(Catalog # SA1022) with DAB as the chromogen.

•

  Figure 4. IHC analysis of Hsp60 using anti-Hsp60 antibody (PB9337).Hsp60 was detected in paraffin-embedded section of Human Intestinal Cancer Tissue. Heat mediated antigen retrieval was performed in citrate buffer (pH6, epitope retrieval solution) for 20 mins. The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 1μg/ml rabbit anti-Hsp60 Antibody (PB9337) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC)(Catalog # SA1022) with DAB as the chromogen.

•

  Figure 5. ICC analysis of Hsp60 using anti-Hsp60 antibody (PB9337).
  Hsp60 was detected in immunocytochemical section of SMMC-7721 Cell. Enzyme antigen retrieval was performed using IHC enzyme antigen retrieval reagent (AR0022) for 15 mins. The cells were blocked with 10% goat serum. And then incubated with 1μg/ml rabbit anti-Hsp60 Antibody (PB9337) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The section was developed using Strepavidin-Biotin-Complex (SABC)(Catalog # SA1022) with DAB as the chromogen.

•

  Figure 6. IF analysis of Hsp60 using anti-Hsp60 antibody (PB9337).
  Hsp60 was detected in immunocytochemical section of U20S cell. Enzyme antigen retrieval was performed using IHC enzyme antigen retrieval reagent (AR0022) for 15 mins. The cells were blocked with 10% goat serum. And then incubated with 2μg/mL rabbit anti-Hsp60 Antibody (PB9337) overnight at 4°C. DyLight488 Conjugated Goat Anti-Rabbit IgG (BA1127) was used as secondary antibody at 1:100 dilution and incubated for 30 minutes at 37°C. The section was counterstained with DAPI. Visualize using a fluorescence microscope and filter sets appropriate for the label used.
