Anti-Beta Tubulin/TUBB Antibody (Clone#2E11)

筛选器： All WB ICC/IF FCM

•

  Western blot analysis of anti-Beta Tubulin/TUBB antibody (M05613-4). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
  Lane 1: human Hela whole cell lysates,
  Lane 2: human HepG2 whole cell lysates,
  Lane 3: human K562 whole cell lysates,
  Lane 4: human Raji whole cell lysates,
  Lane 5: rat brain tissue lysates,
  Lane 6: rat lung tissue lysates,
  Lane 7: mouse brain tissue lysates,
  Lane 8: mouse lung tissue lysates.
  After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with mouse anti-Beta Tubulin/TUBB antigen affinity purified monoclonal antibody (M05613-4) at a dilution of 1:1000 and probed with a goat anti-mouse IgG-HRP secondary antibody (Catalog # BA1050). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for Beta Tubulin/TUBB at approximately 55 kDa. The expected band size for Beta Tubulin/TUBB is at 50 kDa.

•

  Western blot analysis of Beta Tubulin/TUBB using anti-Beta Tubulin/TUBB antibody (M05613-4). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
  Lane 1: human Hela whole cell lysates,
  Lane 2: human HepG2 whole cell lysates,
  Lane 3: human K562 whole cell lysates,
  Lane 4: human Raji whole cell lysates,
  Lane 5: rat brain tissue lysates,
  Lane 6: rat lung tissue lysates,
  Lane 7: mouse brain tissue lysates,
  Lane 8: mouse lung tissue lysates.
  After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with mouse anti-Beta Tubulin/TUBB antigen affinity purified monoclonal antibody (M05613-4) at a dilution of 1:1000 and probed with a DyLight 647 Conjugated AffiniPure Goat Anti-mouse IgG (H+L) secondary antibody (Catalog # BA1151). A specific band was detected for Beta Tubulin/TUBB at approximately 50 kDa. The expected band size for Beta Tubulin/TUBB is at 50 kDa.

•

  IF analysis of Beta Tubulin/TUBB using anti-Beta Tubulin/TUBB antibody (M05613-4).
  Beta Tubulin/TUBB was detected in an immunocytochemical section of U2OS cells. The section was incubated with mouse anti-Beta Tubulin/TUBB Antibody (M05613-4) at a dilution of 1:100. Dylight488-conjugated Anti-mouse IgG Secondary Antibody (green)(Catalog#BA1126) was used as secondary antibody. The section was counterstained with DAPI (Catalog # AR1176) (Blue).

•

  IF analysis of Beta Tubulin/TUBB using anti-Beta Tubulin/TUBB antibody (M05613-4).
  Beta Tubulin/TUBB was detected in an immunocytochemical section of U2OS cells. The section was incubated with mouse anti-Beta Tubulin/TUBB Antibody (M05613-4) at a dilution of 1:100. Dylight488-conjugated Anti-mouse IgG Secondary Antibody (green)(Catalog#BA1126) was used as secondary antibody. The section was counterstained with DAPI (Catalog # AR1176) (Blue).

•

  Flow Cytometry analysis of U937 cells using anti-Beta Tubulin/TUBB antibody (M05613-4).
  Overlay histogram showing U937 cells stained with M05613-4 (Blue line). To facilitate intracellular staining, cells were fixed with 4% paraformaldehyde and permeabilized with permeabilization buffer. The cells were blocked with 10% normal goat serum. And then incubated with mouse anti-Beta Tubulin/TUBB Antibody (M05613-4) at 1:100 dilution for 30 min at 20°C. DyLight®488 conjugated goat anti-mouse IgG (BA1126) was used as secondary antibody at 1:100 dilution for 30 minutes at 20°C. Isotype control antibody (Green line) was mouse IgG at 1:100 dilution used under the same conditions. Unlabelled sample without incubation with primary antibody and secondary antibody (Red line) was used as a blank control.

•
