| Western blot (WB): | 1:500-2000 |
| Immunohistochemistry (IHC): | 1:50-400 |
| (Boiling the paraffin sections in 10mM citrate buffer,pH6.0,or PH8.0 EDTA repair liquid for 20 mins is required for the staining of formalin/paraffin sections.) Optimal working dilutions must be determined by end user. | |

Western blot analysis of anti- CTSD antibody (BM1577). The sample well of each lane was loaded with 50ug of sample under reducing conditions.
Lane 1: human placenta tissue lysates,
Lane 2: A549 whole cell lysates,
Lane 3: PC-3 whole cell lysates,
Lane 4: Hela whole cell lysates,
Lane 5: HepG2 whole cell lysates,
Lane 6: rat RH35 whole cell lysates,
Lane 7: A431 whole cell lysates,
Lane 8: MCF-7 whole cell lysates.
Use mouse anti- CTSD 1:1000, probed with a goat anti-mouse IgG-HRP secondary antibody. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1001). A specific band was detected for CTSD at approximately 28KD. The expected band size for CTSD is at 45KD.

IHC analysis using anti- CTSD antibody (BM1577). detected in paraffin-embedded section of Human Intestinal Cancer tissue. Biotinylated goat anti-mouse IgG was used as secondary antibody. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1021) with DAB as the chromogen.

IHC analysis using anti- CTSD antibody (BM1577). detected in paraffin-embedded section of Human lung Cancer tissue. Biotinylated goat anti-mouse IgG was used as secondary antibody. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1021) with DAB as the chromogen.

IHC analysis using anti- CTSD antibody (BM1577). detected in paraffin-embedded section of Human Mammary Cancer tissue. Biotinylated goat anti-mouse IgG was used as secondary antibody. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1021) with DAB as the chromogen.

Western blot analysis of anti- CTSD antibody (BM1577). The sample well of each lane was loaded with 50ug of sample under reducing conditions.
Lane 1: human placenta tissue lysates,
Lane 2: A549 whole cell lysates,
Lane 3: PC-3 whole cell lysates,
Lane 4: Hela whole cell lysates,
Lane 5: HepG2 whole cell lysates,
Lane 6: rat RH35 whole cell lysates,
Lane 7: A431 whole cell lysates,
Lane 8: MCF-7 whole cell lysates.
Use mouse anti- CTSD 1:1000, probed with a goat anti-mouse IgG-HRP secondary antibody. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1001). A specific band was detected for CTSD at approximately 28KD. The expected band size for CTSD is at 45KD.

IHC analysis using anti- CTSD antibody (BM1577). detected in paraffin-embedded section of Human Intestinal Cancer tissue. Biotinylated goat anti-mouse IgG was used as secondary antibody. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1021) with DAB as the chromogen.

IHC analysis using anti- CTSD antibody (BM1577). detected in paraffin-embedded section of Human lung Cancer tissue. Biotinylated goat anti-mouse IgG was used as secondary antibody. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1021) with DAB as the chromogen.

IHC analysis using anti- CTSD antibody (BM1577). detected in paraffin-embedded section of Human Mammary Cancer tissue. Biotinylated goat anti-mouse IgG was used as secondary antibody. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1021) with DAB as the chromogen.
