| Western blot (WB): | 1:500-2000 |
| Immunohistochemistry (IHC): | 1:50-400 |
| (Boiling the paraffin sections in 10mM citrate buffer,pH6.0,or PH8.0 EDTA repair liquid for 20 mins is required for the staining of formalin/paraffin sections.) Optimal working dilutions must be determined by end user. | |

IHC analysis of Complement C5 using anti-Complement C5 antibody (PA2308).
Complement C5 was detected in a paraffin-embedded section of mouse spleen tissue. The tissue section was incubated with rabbit anti-Complement C5 Antibody (PA2308) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.

IHC analysis of Complement C5 using anti-Complement C5 antibody (PA2308).
Complement C5 was detected in a paraffin-embedded section of rat liver tissue. The tissue section was incubated with rabbit anti-Complement C5 Antibody (PA2308) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.

IHC analysis of Complement C5 using anti-Complement C5 antibody (PA2308).
Complement C5 was detected in a paraffin-embedded section of rat spleen tissue. The tissue section was incubated with rabbit anti-Complement C5 Antibody (PA2308) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.

Western blot analysis of Complement C5 using anti-Complement C5 antibody (PA2308). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: Rat Liver tissue lysates at 40ug,
Lane 2: Mouse Liver tissue lysates at40ug,
Lane 3: NIH whole cell lysates at 40ug,
Lane 4: HEPA whole cell lysates at 40ug,
Lane 5: PC12 whole cell lysates at 40ug.
After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-Complement C5 antigen affinity purified polyclonal antibody (PA2308) at a dilution of 1:1000 and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for Complement C5 at approximately 75 kDa/115 kDa. The expected band size for Complement C5 is at 9 kDa.

IHC analysis of Complement C5 using anti-Complement C5 antibody (PA2308).
Complement C5 was detected in a paraffin-embedded section of mouse spleen tissue. The tissue section was incubated with rabbit anti-Complement C5 Antibody (PA2308) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.

IHC analysis of Complement C5 using anti-Complement C5 antibody (PA2308).
Complement C5 was detected in a paraffin-embedded section of rat liver tissue. The tissue section was incubated with rabbit anti-Complement C5 Antibody (PA2308) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.

IHC analysis of Complement C5 using anti-Complement C5 antibody (PA2308).
Complement C5 was detected in a paraffin-embedded section of rat spleen tissue. The tissue section was incubated with rabbit anti-Complement C5 Antibody (PA2308) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.

Western blot analysis of Complement C5 using anti-Complement C5 antibody (PA2308). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: Rat Liver tissue lysates at 40ug,
Lane 2: Mouse Liver tissue lysates at40ug,
Lane 3: NIH whole cell lysates at 40ug,
Lane 4: HEPA whole cell lysates at 40ug,
Lane 5: PC12 whole cell lysates at 40ug.
After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-Complement C5 antigen affinity purified polyclonal antibody (PA2308) at a dilution of 1:1000 and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for Complement C5 at approximately 75 kDa/115 kDa. The expected band size for Complement C5 is at 9 kDa.
