| Western blot (WB): | 1:500-2000 |
| Immunohistochemistry (IHC): | 1:50-400 |
| Immunocytochemistry/Immunofluorescence (ICC/IF): | 1:50-400 |
| ImmunoPrecipitation (IP): | 1:50 |
| Flow Cytometry (FCM): | 1-3 μg/1x106 cells |
| Enzyme linked immunosorbent assay (ELISA): | 1:100-1000 |
| (Boiling the paraffin sections in 10mM citrate buffer,pH6.0,or PH8.0 EDTA repair liquid for 20 mins is required for the staining of formalin/paraffin sections.) Optimal working dilutions must be determined by end user. | |

Western blot analysis of anti-IRF3 antibody (A00165-7). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: human Hela whole cell lysates,
Lane 2: human Jurkat whole cell lysates,
Lane 3: human Raji whole cell lysates,
Lane 4: human HepG2 whole cell lysates.
After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-IRF3 antigen affinity purified polyclonal antibody (A00165-7) and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for IRF3 at approximately 50-55 kDa. The expected band size for IRF3 is at 47 kDa.

IHC analysis of IRF3 using anti-IRF3 antibody (A00165-7) .
IRF3 was detected in a paraffin-embedded section of human colorectal adenocarcinoma tissue. The tissue section was incubated with rabbit anti-IRF3 Antibody (A00165-7) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.

IHC analysis of IRF3 using anti-IRF3 antibody (A00165-7) .
IRF3 was detected in a paraffin-embedded section of human bladder urothelial carcinoma tissue. The tissue section was incubated with rabbit anti-IRF3 Antibody (A00165-7) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.

ICC/IF analysis of IRF3 using anti-IRF3 antibody (A00165-7).
IRF3 was detected in an immunocytochemical section of Hela cells. The section was incubated with rabbit anti-IRF3 Antibody (A00165-7) at a dilution of 1:100. Fluoro488 Conjugated Goat Anti-Rabbit IgG (Green) (Catalog # BA1127) was used as secondary antibody. The section was counterstained with DAPI (Catalog # AR1176) (Blue).

Western blot analysis of anti-IRF3 antibody (A00165-7). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: human Hela whole cell lysates,
Lane 2: human Jurkat whole cell lysates,
Lane 3: human Raji whole cell lysates,
Lane 4: human HepG2 whole cell lysates.
After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-IRF3 antigen affinity purified polyclonal antibody (A00165-7) and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for IRF3 at approximately 50-55 kDa. The expected band size for IRF3 is at 47 kDa.

IHC analysis of IRF3 using anti-IRF3 antibody (A00165-7) .
IRF3 was detected in a paraffin-embedded section of human colorectal adenocarcinoma tissue. The tissue section was incubated with rabbit anti-IRF3 Antibody (A00165-7) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.

IHC analysis of IRF3 using anti-IRF3 antibody (A00165-7) .
IRF3 was detected in a paraffin-embedded section of human bladder urothelial carcinoma tissue. The tissue section was incubated with rabbit anti-IRF3 Antibody (A00165-7) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.

ICC/IF analysis of IRF3 using anti-IRF3 antibody (A00165-7).
IRF3 was detected in an immunocytochemical section of Hela cells. The section was incubated with rabbit anti-IRF3 Antibody (A00165-7) at a dilution of 1:100. Fluoro488 Conjugated Goat Anti-Rabbit IgG (Green) (Catalog # BA1127) was used as secondary antibody. The section was counterstained with DAPI (Catalog # AR1176) (Blue).
