Figure 1. Western blot analysis of ALCAMA using anti-ALCAMA antibody (AZQ90460). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: zebrafish head tissue lysates.
Lane 2: whole female zebrafish tissue lysates.
Lane 3: whole male zebrafish tissue lysates.
After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-ALCAMA antigen affinity purified polyclonal antibody (AZQ90460) at a dilution of 1:1000 and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for ALCAMA at approximately 95 kDa. The expected band size for ALCAMA is at 61 kDa.
-
Figure 2. IHC analysis of ALCAMA using anti-ALCAMA antibody (AZQ90460) .
ALCAMA was detected in a paraffin-embedded section of zebrafish brain tissue. The tissue section was incubated with rabbit anti-ALCAMA Antibody (AZQ90460) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.
-
Figure 3. IHC analysis of ALCAMA using anti-ALCAMA antibody (AZQ90460) .
ALCAMA was detected in a paraffin-embedded section of zebrafish heart tissue. The tissue section was incubated with rabbit anti-ALCAMA Antibody (AZQ90460) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.
-
Figure 4. IHC analysis of ALCAMA using anti-ALCAMA antibody (AZQ90460) .
ALCAMA was detected in a paraffin-embedded section of zebrafish liver tissue. The tissue section was incubated with rabbit anti-ALCAMA Antibody (AZQ90460) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.
-
Figure 5. IHC analysis of ALCAMA using anti-ALCAMA antibody (AZQ90460) .
ALCAMA was detected in a paraffin-embedded section of zebrafish colon tissue. The tissue section was incubated with rabbit anti-ALCAMA Antibody (AZQ90460) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.
-
Figure 6. IHC analysis of ALCAMA using anti-ALCAMA antibody (AZQ90460) .
ALCAMA was detected in a paraffin-embedded section of zebrafish muscle tissue. The tissue section was incubated with rabbit anti-ALCAMA Antibody (AZQ90460) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.
-
Figure 7. IHC analysis of ALCAMA using anti-ALCAMA antibody (AZQ90460) .
ALCAMA was detected in a paraffin-embedded section of zebrafish kidney tissue. The tissue section was incubated with rabbit anti-ALCAMA Antibody (AZQ90460) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.
